| enum | Type : uint8_t { SOCKET_CONNECTOR,
MEMIF_CONNECTOR,
LOOPBACK_CONNECTOR
} |
| |
| enum | State : std::uint8_t { CLOSED,
CONNECTING,
CONNECTED
} |
| |
| enum | Role : std::uint8_t { CONSUMER,
PRODUCER
} |
| |
|
using | Ptr = std::shared_ptr< Connector > |
| |
|
using | PacketQueue = std::deque< Packet::Ptr > |
| |
|
using | PacketReceivedCallback = std::function< void(Connector *, utils::MemBuf &, const std::error_code &)> |
| |
|
using | PacketSentCallback = std::function< void(Connector *, const std::error_code &)> |
| |
|
using | OnCloseCallback = std::function< void(Connector *)> |
| |
|
using | OnReconnectCallback = std::function< void(Connector *)> |
| |
|
using | Id = std::uint64_t |
| |
|
|
template<typename ReceiveCallback , typename SentCallback , typename OnClose , typename OnReconnect > |
| | Connector (ReceiveCallback &&receive_callback, SentCallback &&packet_sent, OnClose &&close_callback, OnReconnect &&on_reconnect) |
| |
|
template<typename ReceiveCallback > |
| void | setReceiveCallback (ReceiveCallback &&callback) |
| |
|
template<typename SentCallback > |
| void | setSentCallback (SentCallback &&callback) |
| |
|
template<typename OnClose > |
| void | setOnCloseCallback (OnClose &&callback) |
| |
|
template<typename OnReconnect > |
| void | setReconnectCallback (const OnReconnect &&callback) |
| |
|
const PacketReceivedCallback & | getReceiveCallback () const |
| |
|
const PacketSentCallback & | getSentCallback () |
| |
|
const OnCloseCallback & | getOnCloseCallback () |
| |
|
const OnReconnectCallback & | getOnReconnectCallback () |
| |
|
virtual void | send (Packet &packet)=0 |
| |
|
virtual void | send (const uint8_t *packet, std::size_t len)=0 |
| |
|
virtual void | close ()=0 |
| |
|
virtual State | state () |
| |
|
virtual bool | isConnected () |
| |
|
void | setConnectorId (Id connector_id) |
| |
|
Id | getConnectorId () |
| |
|
void | setConnectorName (std::string connector_name) |
| |
|
std::string | getConnectorName () |
| |
|
Endpoint | getLocalEndpoint () |
| |
|
Endpoint | getRemoteEndpoint () |
| |
|
void | setRole (Role r) |
| |
|
Role | getRole () |
| |
|
|
static utils::MemBuf::Ptr | getPacketFromBuffer (uint8_t *buffer, std::size_t size) |
| |
|
static std::pair< uint8_t *, std::size_t > | getRawBuffer () |
| |
|
|
static constexpr std::size_t | queue_size = 4096 |
| |
|
static constexpr std::uint32_t | invalid_connector = ~0 |
| |
|
|
PacketQueue | output_buffer_ |
| |
|
PacketReceivedCallback | receive_callback_ |
| |
|
PacketSentCallback | sent_callback_ |
| |
|
OnCloseCallback | on_close_callback_ |
| |
|
OnReconnectCallback | on_reconnect_callback_ |
| |
|
std::atomic< State > | state_ |
| |
|
Id | connector_id_ |
| |
|
Endpoint | local_endpoint_ |
| |
|
Endpoint | remote_endpoint_ |
| |
|
std::string | connector_name_ |
| |
|
Role | role_ |
| |
|
AtomicConnectorStats | stats_ |
| |
The documentation for this class was generated from the following file:
